Other Meters

• Meeting IEC 61000-4-7 harmonic measurement (50/60Hz)

• Wiring selecting button (1P3W,3P3W,3P4W,3V3A)

• Voltage/Current Test Freq. Bandwidth: DC, 0.1Hz~ 100kHz

• DC, 0.1Hz ~ 100kHz voltage/current test bandwidth

•50th order of harmonic measurement and analysis (value and bar graph)

• Waveform display: V (voltage), I (current), P (power)

• xternal current sensor input terminals (EXT1/EXT2)

• Standard interfaces: RS-232C, USB device/ host, LAN, GPIB

• Met the requirement of IEC 62301 power measurement

• Voltage/ current test frequency bandwidth : DC~6kHz

• W-h (power vs time)/A-h (current vs time) integration function

• Total harmonic distortion measurement

• Standard interface : RS-232C, USB device, LAN

• 50,000 counts

• 1Amp test current, 0.1µΩ resolution

• Fast measurement of 60 readings per second

• High accuracy of 0.05% precision

• Voltage measurement: 300V (GBM-3300) or 80V (GBM-3080)

• Resistance measurement: 0mΩ~ 3.2kΩ(max.)

• Measurement items: DC voltage and AC resistance
