• Analog Oscilloscopes And Digital Storage Oscilloscope
GDS- 1000B Series Digital Storage Oscilloscope
• Products Feature
200/100/70/50 MHz : 2 Channel models ;100/70/50 MHz : 4 Channel models
1GSa/s Maximum Sampling Rate
10M Maximum Memory Depth For Each Channel
7” 800 x 480 WVGA LCD Display
256 Color Gradient Display Function to Strengthen Waveform Performance
1Mpts FFT Frequency Domain Signal Display
12 C/SPI/UART/CAN/LIN Serial Bus Trigger and Decoding Functions
Zero Key Function For Horizontal Time, Vertical Voltage and Triggering
GDS- 2000A Series Digital Storage Oscilloscope
• Products Feature
• 300/200/100/70MHz Bandwidth, 2 or 4 Input Channels
• 2GSa/s Maximum Real-Time Sampling Rate and 100GSa/s Equivalent Time Sampling Rate
• 2M points Maximum Record length
• VPO Technology to Display Less- Frequently-Occurred Signals
• Fast Update Rate of 80,000 Waveform Per Second
• Segmented Memory Acquisition and Waveform Search Function
• Standard Model Provides I C, UART, SPI Serial Bus Trigger and Analysis Functionality
• Optional 8 or 16 Additional Digital Channels with Logic Analyzer(MSO) Upgradable CAN/LIN Bus, DVM, H-Expansion, Data Log and Advanced Logic Functionality
• Optional 5MHz & 25MHz Function Generator
• Flexible Remote Control Connectivity (Standard : USB ; Optional : LAN/GPIB)
GDS- 2000E Series Digital Storage Oscilloscope
• Products Feature
• 200/100/70 MHz Bandwidth
• Sampling Rate: Max.1Gsa /s(4ch Model) Per Channel 1 GSa/s (2ch Model)
• 10M Maximum Memory Depth and VPO Waveform Disply Technology
• Waveform Updae Rate of 120,000 wfm/s
• 8" 800 X 480 TFT LCD Disply
• Max.1M pts of FFT to get Higher Resoloution in Frequency Domain.
• Digital Filter Function
•Segmented memory and Waveform Search Function
• 12 C/SPI/URAT/CAN/LIN Serial Bus trigger and Deconding Function.
• Data log Function for Waveform observation in logng Periods of time
• Network Storage Function
GDS- 3000 Series Digital Storage Oscilloscope
• Products Feature
500/350MHz Bandwidth
Dual Sampling Modes: 5GSa/s Real-Time Sampling Rate and 100GSa/s Equivalent Time Sampling Rate
25k Points Memory for Each Input Channel
VPO (Visual Persistence Oscilloscope) Technology to Display Less-Frequently-Occurred Signals
8" 800 x 600 High Resolution TFT LCD Display
Unique Split Screen System with Independent Setting for Each Input Channel
Three Input Impedance Selections:50 /75 /1M ΩΩ Ωs
Optional Power Measurement Software for Power Supply Measurement and Analysis
Optional Serial BUS Triggering and Decoding Software Supporting I C, SPI and UART
Support GW APP Software-Easy Upgrade of Feature New Function
• Spectrum Analyzer
GSP 9330 TG (High End 3.3 GHz Spectrum Analyzer)
• Products Feature
• DDS Technology and FPGA Designed
• Frequency Range : 9 kHz ~ 3.25 GHz
• Fastest sweep speed up to 204 us
• Support modulation signal analysis
• 2FSK digital signal analysis
• ASK/FSK digital signals demodulation and analysis
• AM/FM analog signals demodulation and analysis
• Complete EMC pretest solution
• EMI Detect mode: Quasi-Peak, Average
• EMI Filter(-6dB): 200 Hz, 9 kHz, 120 kHz, 1MHz
• Dedicated EMC function key
GSP-730 (Economical Version 3 GHz Spectrum Analyzer)
• Products Feature
• Autoset Function
• Noise level : 5-"100dBm
• RBW Range : 30kHz,100kHz,300kHz,1 MHz
• ACPR/CHPW/OCBW Measurement
• 3 Traces in Different Colors
• Split Window Function
• Limit Line Function
• Remote Control Software
• Presentation Material for Training Courses
• Support Interface: USB Device Host,RS-232C
• 5.6" TFT LCD with VGA Output
GSP-818 (Economical Version 1.8 GHz Spectrum Analyzer)
• Products Feature
• Frequency Range: 9kHz ~ 1.8GHz
• RBW: 10Hz ~ 3MHz, 10Hz ~ 500kHz in 1-10 steps
• Sensitivity:-148dBm/Hz Typical@PreAmp On
• Built-in AM/FM Demodulation
• Bandwidth Zoom Function
• Measurement Function: ACPR/OCBW/ CHPW, NdB Bandwidth, Freq. Counter, Noise Marker, Limit Line
• Built-in 20dB Preamplifier Standard
• Interface: LAN, USB
• Screen: 10.4" SVGA Output (800x600)
• Options: Tracking Generator, EMI Filter & Detector (via software keycode)
• Programmable DC Power Supplies
PSW-Series
• Products Feature
• Voltage Rating : 30V/80V/160V/250V/800V, Output Power Rating : 360W~1080W
• Constant Power Output for Multi-Range, ( V & I ) Operation
• C.V / C.C Priority ; Particularly Suitable for the Battery and LED Industry
• Series Operation (2 units in Series)for(30V/ 80V/160V), Parallel Operation(3 units in Parallel) for (30V/80V/160V/250V/800V)
• High Efficiency and High Power Density
• 1/2, 1/3, 1/6 Rack Mount Size Design ( EIA/JIS Standard ) for 360W, 720W, 1080W
• Standard Interface : LAN, USB, Analog Control Interface
• Optional Interface : GPIB-USB Adaptor,RS232-USB Cable
• LabVIEW Driver
PSU Series
• Products Feature
• Voltage Output : 6V/12.5V/20V/40V/60V/ 100V/150V/300V/400V/600V
• Power Output : 1200W ~ 1560W
• C.V/C.C Priority Mode
• Adjustable Voltage/Current Rise and Fall Time
•Series/Parallel Connection : Max. 2 units (Models Under 300V)/4 units of The Same Mode
• High Efficiency and High Power Density
• 1U Height and 19”Rack Mount Size
• Three sets of Preset Function
• Bleeder Control Function
• Internal Resistance Function
• PProtection : OVP, OCP, OHP, UVL, AC Fail,FAN Fail
• Standard : USB, LAN, RS-232, RS-485, Analog Control
• Option : GPIB, Isolated Analog Interface (Voltage Control/Current Control)
PLR Series
• Products Feature
• Output Power:36 360 W/ 720W
• Low Rippele and Noise(0.5m Vrms/ 10m Arms)
• Fast Transition Recovery Time (100µs)
• Equipment Power Factor correction Circuit for AC _input 100-240VAC
• Maximum 2 units i series Conections or 3 units in parallel connection
• Select the setting Digits for Voltage and currentn(Course / Fine Volume control)
• Panel Lock FUnction /3 set of preset Function.
• Output Off Timer Function (Range : 1 min to 1000 hours & 59mins)
• CC Pririty Function (Prevent Overshoot & inrush current))
• Sequence Functionof PC Editing (Max:100 steps / Min.step Period:50ms)
• Protectio :OVP, UVP, OCP Remote Sensing (Terminal Open)
• External Amalog Control Function
• PC Remote Interface Standard: RS-232
• PC Remote Interface Standard: LAN . USB. GPIB/ USB External Anlog Control
GPP Series
• Products Feature
• 4.3”TFT LCD Display
• Supports Setting Value, Measurement Value and Output Waveform Display
• Load Function (CC, CV, CR Mode)
• Setting Resolution: 1mV / 0.1mA; Read Back Resolution: 0.1mV / 0.1mA
• Low Ripple Noise: ≦350uVrms/ ≦2mArms
• Transient responsee Time: ≦50uS
• Utilizing Hardware to Realize Over Voltage Protection / Over Current Protection / Over Temperature Protection
• Delay Function / Output Monitoring Function / Output Recorder Function
• Intelligent Temperature Control Fan Effectively Reduces Noise
• Sequential Output Function and Built-in 8 Template Waveforms
• Sequential Output Function and Built-in 8 Template Waveforms
• Linear DC Power Supplies
GPE-X323
• Products Feature
• Setting & Read Back Resolution 100mV/10mA (*1)
• Output On/off
• Analog Control (Remote I/O) For Output ON/OFF
• Set View Function For Checking an Original V/I Setting During Output On
• Key Lock Function
• Tracking Series And Parallel Operation
• Smart Cooling Fan Achieving Low Noise
• Optional European Jack Type Terminal
GPS Series
• Products Feature
• Light and Compact Design
• 0.01% High Regulation
• Constant Voltage and Constant Current Operation
• Remote Control for External Programmability
• Internal Select for Continuous or Dynamic Load
• Low Ripple and Noise
• Overload and Reverse Polarity Protection
• Series or Parallel Operation
• Optional European Type Jack Terminal for GPS-3030/GPS-3030D/GPS-3030DD
GPR Series
• Products Feature
• 0.01% High Regulation
• Constant Voltage and Constant Current Operation
• Internal Select for Continuous or Dynamic Load
• Low Ripple and Noise
• Overload and Reverse Polarity Protection
• 3 1/2 Digit 0.5" LED Display
• Internal Select for Continuous or Dynamic Load (for GPR-3510HD/GPR-6060D/GPR-7550D)
• Programmable AC Power Supplies
APS Series
• Products Feature
• 4.3” large LCD Display
• Output Capacity:APS-7050E(500VA, 310Vrms, 4.2/2.1Arms)APS-7100E(1000VA, 310Vrms, 8.4/4.2Arms)
• Measurement Function : Voltage, Current, Power, Frequency, Power Factor, Ipeak
• Reverse Current Alarm Function
• 10 Sets of The Test Mode Simulate Power Transient Output
• 10 Sets of Preset Allow Users to Store Ten Settings
• OCP/OPP/OTP Protection
• Variable Voltage, Frequency and Current Limiter
• Universal Power Inlet
ASR Series
• Products Feature
• Output Rating: AC 0 400 Vrms, ~ DC 0 ~ ± 570 V
• Output Frequency up to 999.9 Hz
• DC Output (100% of Rated Power)
• Measurement Items: Vrms, Vavg, Vpeak, Irms, IpkH, Iavg, Ipeak, P, S, Q, PF, CF
• Voltage and Current Harmonic Analysis(THDv, THDi)
• 1 Remote Sensing Capability
• * OCP, OPP, OTP, AC Fail Detection and Fan Fail Alarm
• Support Arbitrary Waveform Function
• Output Capacity: 2kVA/ 3kVA/4kVA
• Customized Phase Angle for Output On/Off
• Sequence and Simulation Function (up to 10 sets)
• Interface(std):USB,LAN,RS-232,GPIB
• Built-in External Control I/O and External Signal Input
• Built-in Output Relay Control
• Memory Function (up to 10 sets)
• Built-in Web Server
• AC and DC Power Supplies
• Programmable DC Power Supplies
PSW-Series
• Products Feature
• Voltage Rating : 30V/80V/160V/250V/800V, Output Power Rating : 360W~1080W
• Constant Power Output for Multi-Range, ( V & I ) Operation
• C.V / C.C Priority ; Particularly Suitable for the Battery and LED Industry
• Series Operation (2 units in Series)for(30V/ 80V/160V), Parallel Operation(3 units in Parallel) for (30V/80V/160V/250V/800V)
• High Efficiency and High Power Density
• 1/2, 1/3, 1/6 Rack Mount Size Design ( EIA/JIS Standard ) for 360W, 720W, 1080W
• Standard Interface : LAN, USB, Analog Control Interface
• Optional Interface : GPIB-USB Adaptor,RS232-USB Cable
• LabVIEW Driver
PSU Series
• Products Feature
• Voltage Output : 6V/12.5V/20V/40V/60V/ 100V/150V/300V/400V/600V
• Power Output : 1200W ~ 1560W
• C.V/C.C Priority Mode
• Adjustable Voltage/Current Rise and Fall Time
•Series/Parallel Connection : Max. 2 units (Models Under 300V)/4 units of The Same Mode
• High Efficiency and High Power Density
• 1U Height and 19”Rack Mount Size
• Three sets of Preset Function
• Bleeder Control Function
• Internal Resistance Function
• PProtection : OVP, OCP, OHP, UVL, AC Fail,FAN Fail
• Standard : USB, LAN, RS-232, RS-485, Analog Control
• Option : GPIB, Isolated Analog Interface (Voltage Control/Current Control)
PLR Series
• Products Feature
• Output Power:36 360 W/ 720W
• Low Rippele and Noise(0.5m Vrms/ 10m Arms)
• Fast Transition Recovery Time (100µs)
• Equipment Power Factor correction Circuit for AC _input 100-240VAC
• Maximum 2 units i series Conections or 3 units in parallel connection
• Select the setting Digits for Voltage and currentn(Course / Fine Volume control)
• Panel Lock FUnction /3 set of preset Function.
• Output Off Timer Function (Range : 1 min to 1000 hours & 59mins)
• CC Pririty Function (Prevent Overshoot & inrush current))
• Sequence Functionof PC Editing (Max:100 steps / Min.step Period:50ms)
• Protectio :OVP, UVP, OCP Remote Sensing (Terminal Open)
• External Amalog Control Function
• PC Remote Interface Standard: RS-232
• PC Remote Interface Standard: LAN . USB. GPIB/ USB External Anlog Control
GPP Series
• Products Feature
• 4.3”TFT LCD Display
• Supports Setting Value, Measurement Value and Output Waveform Display
• Load Function (CC, CV, CR Mode)
• Setting Resolution: 1mV / 0.1mA; Read Back Resolution: 0.1mV / 0.1mA
• Low Ripple Noise: ≦350uVrms/ ≦2mArms
• Transient responsee Time: ≦50uS
• Utilizing Hardware to Realize Over Voltage Protection / Over Current Protection / Over Temperature Protection
• Delay Function / Output Monitoring Function / Output Recorder Function
• Intelligent Temperature Control Fan Effectively Reduces Noise
• Sequential Output Function and Built-in 8 Template Waveforms
• Sequential Output Function and Built-in 8 Template Waveforms
• Linear DC Power Supplies
GPE-X323
• Products Feature
• Setting & Read Back Resolution 100mV/10mA (*1)
• Output On/off
• Analog Control (Remote I/O) For Output ON/OFF
• Set View Function For Checking an Original V/I Setting During Output On
• Key Lock Function
• Tracking Series And Parallel Operation
• Smart Cooling Fan Achieving Low Noise
• Optional European Jack Type Terminal
GPS Series
• Products Feature
• Light and Compact Design
• 0.01% High Regulation
• Constant Voltage and Constant Current Operation
• Remote Control for External Programmability
• Internal Select for Continuous or Dynamic Load
• Low Ripple and Noise
• Overload and Reverse Polarity Protection
• Series or Parallel Operation
• Optional European Type Jack Terminal for GPS-3030/GPS-3030D/GPS-3030DD
GPR Series
• Products Feature
• 0.01% High Regulation
• Constant Voltage and Constant Current Operation
• Internal Select for Continuous or Dynamic Load
• Low Ripple and Noise
• Overload and Reverse Polarity Protection
• 3 1/2 Digit 0.5" LED Display
• Internal Select for Continuous or Dynamic Load (for GPR-3510HD/GPR-6060D/GPR-7550D)
• Programmable AC Power Supplies
APS Series
• Products Feature
• 4.3” large LCD Display
• Output Capacity:APS-7050E(500VA, 310Vrms, 4.2/2.1Arms)APS-7100E(1000VA, 310Vrms, 8.4/4.2Arms)
• Measurement Function : Voltage, Current, Power, Frequency, Power Factor, Ipeak
• Reverse Current Alarm Function
• 10 Sets of The Test Mode Simulate Power Transient Output
• 10 Sets of Preset Allow Users to Store Ten Settings
• OCP/OPP/OTP Protection
• Variable Voltage, Frequency and Current Limiter
• Universal Power Inlet
ASR Series
• Products Feature
• Output Rating: AC 0 400 Vrms, ~ DC 0 ~ ± 570 V
• Output Frequency up to 999.9 Hz
• DC Output (100% of Rated Power)
• Measurement Items: Vrms, Vavg, Vpeak, Irms, IpkH, Iavg, Ipeak, P, S, Q, PF, CF
• Voltage and Current Harmonic Analysis(THDv, THDi)
• 1 Remote Sensing Capability
• * OCP, OPP, OTP, AC Fail Detection and Fan Fail Alarm
• Support Arbitrary Waveform Function
• Output Capacity: 2kVA/ 3kVA/4kVA
• Customized Phase Angle for Output On/Off
• Sequence and Simulation Function (up to 10 sets)
• Interface(std):USB,LAN,RS-232,GPIB
• Built-in External Control I/O and External Signal Input
• Built-in Output Relay Control
• Memory Function (up to 10 sets)
• Built-in Web Server
• High Current, High Voltage AC and DC Power supplies.
Preen- AC Power Corp
• Products Applications
• Aimed at Renewable Energy, Preen Provides Diversified Power Testing Solutions
• EV Testing Solution Part II : DC/DC Converter
• Driving Force behind a Sustainable Future: Solar Array IV Curve Simulation Solutions
• EV Testing Solution Part I : On-Board Battery Charger
• One Giant Leap for LED Chips Testing Efficiencyy
• 1500V Photovoltaic System Simulation Solution
Programmable DC Power Supplies
• High Voltage & High Power – ADG – P Series
Intuitive 7’’Touch Screen for Easy Operation
Output Voltage upto 2000V Renewable Energy Application
Single Unit Power 30KW – 100 Kw
• High Output Current at Low Output Voltage – ADG –L Series
Output Voltage upto 1000 Volts
High Power Density 15 KW in 3 U
High Power Generation by Easy Parallel Combination
Programmable AC Power Supplies
• Single Phase AC Power Source with DC Output – AFV-P Series
Output Power : 600 VA – 5 KVA
Output Voltage 310V ( Opt.620V)
Output Frequency 15 – 1000 Hz
Capable to Simulate Power line Disturbances, such as IEC 61000-4-11
• Three Phase Programmable AC Source- AFV Series
Output power : 10 KVA – 2000 KVA
Output Voltage : 0 – 300 V
Output Frequency 45-65 Hz
Interface : RS 232, RS 485
• Signal Sources
SFG-1003/1013 (3 MHz DDS Function Generator)
• Products Feature
• DDS Technology and FPGA Designed
• Frequency Range : 0. 1Hz ˜ 3MHz
• High Frequency Accuracy : ±20ppm
• High Frequency Stability : ± 20ppm
• Max. Frequency Resolution : 100 mHz
• Low Distrortion Sine Wave : -55dBc,0. 1Hz ˜200 KHz
• Voltage Display ( Only SFG-1013)
AFG-2225 (25MHz TRUE DUAL CHANNEL ARBITRARY FUNCTION GENERATOR)
• Products Feature
• Wide Frequency Ranges From 1µ Hz ~ 25MHz (sine wave)
• 1 µHz Resolution in Full Range
• Built-in Standard 120MSa/s, 10bit, 4k Points Arbitrary Function for Both Channels
• True Dual-Channel Output, CH2 Provides the Same Characteristics as CH1
• Dual-Channel Supports Couple,Tracking, Phase Operations
• 1% ~ 99% Adjustable Duty Cycle for Square Waveform
• Friendly User Interface for Easy Parameter Setting and Parameters Display
• Multiple Editing Methods to Edit Arbitrary Waveform Easily
• Built-in Standard AM/FM/PM/FSK/SUM/ Sweep/Burst and Frequency Counter
• USB Host/Device Interface for Remote Control and Waveform Editing
AFG - 3081/ 3051 (80/50 MHz Arbitrary Function Generator)
• Products Feature
• Wide Frequency Range from 1 µHz 80/50 MHz
• 1 µHz Frequency Resolution throughout Full Range.
• Standerd Waveform : Sine Square, Tringle, Ramp, Pluse Noise
• Built-in AM. FM. PWM, FSK, Sweep, Brust Functions.
• 16bit 200sa/s, 1 M-point Deep Arbitrary Waveform
• DWR (Direct Waveform Reconstruction) Capability
• Arbitrary Waveform Editing PC Software.
• 4.3" High Resolution LCD Display.
• USB, RS-232, GPIB Standard interfaces
MFG 2000 (Multi-Channel Function Generator)
• Products Feature
• Maximum Five output Channels
• 2 Equivalent Performmance Arbitrary channels Frequency : 1µ Hz-10/20/30/60/200MHz
• RF Channel Frequency(FG / ARB/ MOD): 160/ 320MHz
• Pulse Generator Frequency : 25MHz.
• Power Amplifier : Low Frequency, 5hz-100kHz,20db/20db/20W(limeted by current setting)
• True Point by Point Output Arbitrary Waveform Function: MFG-2220HM Sample Rate: 250MSa/s, Repetition Rate: 125MHz; Other models Sample Rate: 200MSa/s, Repetition Rate: 100MHz, 14-bit Resolution, 16k Points Memory Depth
• Earth Ground Isolation Design Among I/O Terminals and Instrument Chassis (MFG-2220H M Excluded)
• Frequency Counter: 150MHz, 8-bit Frequency Resolution
• AM/FM/PM/ASK/FSK/PSK/SUM/PWM Modulation
• Built-in Medical and Automotive Electronic Waveforms
• USB Host/USB Device/LAN (MFG-22XX only)
• 4.3 Inch TFT Color Display
• Digital Multimeter
GDM-906X Dual Measurement Multimeter (6 1/2 Digit Dual Measurement Multimeter)
• Products Feature
• 6 1/2 Digit Display: 1,200,000 Counts.
• 4.3" TFT Graphic LCD
• DCV Basic Accuracy:0.0035% (GDM-9061)/0.00075%(GDM-9060)
• 12 Measurement Functions: DCV, ACV, DCI,ACI, 2-Wire and 4-wire
• Resistance, Frequency, Period, Diode, Continuty, Temperature and Capacitance
• Sampling Rate up to 10K SPS (GDM-9061)
• Dual Measurments to Perform Two Selected Measurmnet Simultaneusly
• Offer Graphical Capabilities including Histogram, Bar Meter and Trend
• Temperature Measurement Support RTD, Thermistor as Well as Thermocouple
• Standard interface: USB Host/ Device, RS-232C, LAN, Digital I/O
• Optional Interface GPIB
GDM-8261 (6 1/2 Digit Dual Measurement Multimeter)
• Products Feature
• 6 1/2 Digit Display: 1,2000, 000 Counts
• DCV Basic Accuracy : 0.0035%
• Dual Measurments to Perform Two Selected Measurments Simultaneously
• Bright Vacuum Fluourscent Display (VFD)
• 11 Measurment Function & 10 Math Function
• High Resolution: Up to 100 pA Resolution with DCI and 1nA with ACI Measurments
• Temperature measurments(RTD & Themocouple) From-2000C~+18200C)
• High Data transmission speed: UP to 2,400 reading/s Thour USB Interface
• Standard Interfaces: USB, RS-223C, Digital I/O
• Optional interface: GPIB Or LAN
• Optional Scanner Card: GDM-SC1A(V ch X 16, I ch X 2)
• Free PC Software: Exel ADD-in, Lab View driver
• Compact Size, Ideal for Automatic Equipment (2U,1/ Rack)
GDM-8351 (5 1/2 Digit Dual Measurement Multimeter)
• Products Feature
• 1200, 000 Counts, VFD Display
•Dual Measurment/ Dual Display
• The Basic Precision of Dc Voltage:0.012%
• Selectable Measurment speeds, The Maximum:320 Reading/s
• Tru RMS (AC, AC + DC) Measurments
• Auto/ Manual Selection
• 12 Diffrent Measurment Functions: AC/ DC Voltage, AC/ DC Current, AC+DC Voltage / Current, 2W/ 4W Resistance, Continuty Beeper Diode Test, Capacitance, Frequency, Temerature
• Many auxiliary Finctions: Max/ Min., REL/ REL #, Compare, Hold, db,dbm, Math(MX+B, % 1/X)
• Digital I/O Provides Dual Mode (Standard Compare and Defination Models)
• Standard RS-232C and USB Device interface USBCDC and USBTMC Models
GDM-8245 (50000 Counts Dual Display Digital Multimeter)
• Products Feature
• * 50000 Counts Display
• Multi-Function ACV, DCV, ACA, DCA, R, C,Hz, Continuity Beeper, Diode Test, Max/Min,REL, Hold, dBm
• Dual Display Indicate ACV and Hz, DCV(ACV)and dBm
• Manual or Auto Ranging
• 0.03% DCV Accuracy
• ACV Measuring Frequency Up to 50kHz
• AC True RMS or AC + DC True RMS
GDM-834X Series(50000 Counts Dual Measurment Multimeter)
• Products Feature
• 50000 Counts Vacuum Flourescent Display With Two Colors
•Dual Measurment
• Fast Measuremenr Rate Up to 40 readings/s for DCV
• 0.02% DCV Basic Accuracy
• Auto/ Manual Ranging
• True RMS (AC, AC+ DC)
• 11 Measurment Functions
• Max/Min., REL, MX+B,1X, Ref% Compare, Hold, db, dbm
• Temperature Measurement(GDM-8342 only)
• USB Storage for Data collection (GDM-8342 only)
• Optional GPIB (factory install for GDM-8342 only)
GDM-400 & GDM 300 (Hand-Held Digital Multimeter)
• 4 ½ Digits Manual Ranging
• AC Current True RMS
• Capacitance, Frequency Measurement
• Data Hold
• Auto Power Off
• LCR
• LCR-900 Series(Hand-Held LCR Meter)
• Products Feature
• 20, 000 /2,000 Counts Dual Display.
• Test Frequency: 100 / 120 Hz/ 1KHz/ 10KHz/100 KHz Depend on Model
• Auto LCR Mode for DUT Measuring
• 0.2% Basic Accuracy
• Measurment Parameters: L, C, R (AC/ DC)D, Q, ESR
• Parallel/ Series Testing Mode
• 2 Wire or 5 Wire Measurement available
• Data Hold and Zero mode suppored
• Max and Min (LCR-916 only)
• Auto Range, Auto Backlit
• Low Battery Indication
• Auto Power off.
• Data collection or DC Power Operation (Optional for LCR-915)
Benchtop LCR meters
• LCR-6000 Series (Precision LCR Meter)
• Products Feature
• 3.5" Color LCD
• 5 Models (10 Hz ~2KHz/ 20 KHz/ 100 KHz / 200 KHz/ 300 KHz)
• Consecutive Test Frequency
• Basic Accuracy: 0.05%
• Measuring Speed up to 25ms (Max.)
• Full Frequency range or Spot OPEN/ SHORT
• 16 Major/ Secondary Parameter measurment Combination and Two Addtional Monitoring Parameters (Maximum Four Diffrent Parameters can be shown Simultaneously)
• DCR Measurement and internal D.C Bias Voltage (+2.5V)
• Pass/ FAIL Judgement
• BIN Function Provides 9BIN and 1 AUX Totally 10 BIN
• 10 Steps Listed Tests to Select Diffrent Frequency Voltage and current Criteria
• Standerd Interface: RS-232C, Handler and USB Storage
• Compact Size, Ideal for Automatic Equipment (2U,1/ Rack)
• LCR -8200 Series (High Frequency LCR Meter)
• Products Feature
• Wide Test Frequency 10Hz ~ 30MHz/20MHz/10MHz/5MHz/1MHz
• 7” LCD color Display
• 0.08% Basic Accuracy
• Displaying Four Measurement Results Simultaneously From
• 17 Selectable Measurement Parameters Freely
• 15 Steps List Measurement
• Two Curves Sweep Mode
• Internal DC Bias Voltage ±12V
• ALC Function Available
• Standard Interfaces : RS-232C, USB Host/Device, LAN,
• GPIB and Handler
• Universal Power Input
• USB USB
• Device Host LAN Trigger Handler
• Electrical Safety Tester
Electrical Safety Tester
GPT-9600 Series AC/DC/IR Electrical Safety Analyzer
• Products Feature
• 100VA AC Test Capacity
• Frequency Range : 9 kHz ~ 3.25 GHz
• 240 x 48 Ice Blue Dot Matrix LCD
• RMS Current Measurement
• ARC Detection
• Zero Crossing Turn-on Operation
• PWM Switching Amplifier to Enhance the Power Efficiency and Reliable Testing
• Automatically Switching Input Source for World-wide Input Voltage
• Light Design and Easy to Operation
GPT-9000 Series AC/DC/IR/GB Electrical Safety Analyzer
• Products Feature
• 500 VA and 200VA AC Test Capacity.
• 240X64 Ice Blue Dot Matrix LCD
• Manual/ Auto Mode
• Function Key for Quick Selecting.
• High Intensity Flash for Caution & Status Indication
• Safery Interlock Function
• Zero Crossing Turn-on Operation.
• Controllable Ramp-up Time
• RMS Current Mesurment
• Internal Storage and USB Storage Available
• High Resolution: 1 A for Measuring Current, 2 V for setting Voltage
• PWM Switching Amplifier to Enhance the Efficiency and Reliable Testing.
• Max. 100 Memory Block, for Test Condtion (Step) Setting And Step Can be Named Individualluy.
• Remote Terminal on the Front Panel for "Start" and "Stop" Control by External.
• Interface: RS-233C, USB Devive, Signal I/o GPIB Optional
GPT-12000 Series : AC/DC/IR/GB Electrical Safety Analyzer
• Products Feature
• 200VA AC Test Capacity
• Comply with IEC 61010-2-034
• 7” TFT LCD & Manual/Auto Mode
• RMS Current Measurement
• Zero Crossing Turn-on Operation
• Controllable Ramp-up & Ramp-down Time
• Capacitive Load Testing Capability up to 47 Fμ
• Statistics Function
• Sweep Function for DUT Characteristic Analysis
• USB Storage Available & Rear Panel Output Available
• Interface:RS-232C,USB Host/Device,Signal I/O and GPIB(Opt.)
• Universal Power Input
GPT-15000 Series AC/DC/IR/GB Electrical Safety Analyzer
• Products Feature
• 5OOVA AC Test Capacity (short circuit current > 200mA)
• 7“ TFT LCD
• Manual Test Mode/Auto Test Mode
• RMS Current Measurement
• Zero Crossing Turn-on Operation
• Controllable Ramp-up & Ramp-down Time
• Statistics & Analysis Function
• Capacitive Load Testing Capability up to 47p F
• Sweep Function for DUT Characteristic Analysis
• Internal Storage and USB Storage Available
• Barcode Function Available
• Setting Data Export/Import
• Rear Panel Output Available
• Standard Interface : RS-232C, USB host/device and Signal I/O
• Optional Interface : GPIB or LAN
• Universal Power Input
